High-Speed & High-Density Connectors

ODU provides various high-speed high-density SMALLER- LIGHTER – FASTER connectors. This environmentally sealed, rugged connectors are ideal for applications that require a high-speed & high-density interconnect solution. Additional product features include: high performance data transmission, high reliability, easy handling, ideal for harsh environment applications.

Product Benefits

High-Speed data transfer: USB® 3.2 Gen 1x1¹ up to 5 Gbit/s, USB® 2.0¹ up to 480 Mbit/s, HDMI®¹ up to 8.16 Gbit/s, Ethernet CAT6 data transfer up to 10 Gbit/s)
High contact density: up to 27 contacts
Push-Pull or Break-Away locking
Pin and groove mechanical keying options
Up to IP6K9K in unmated condition

ODU High-Speed & High-Density Connectors at a Glance

Applications

Featured Solutions

ODU AMC®

> 5,000 mating cycles
High contact density: 2–27 contacts in 3 shell sizes
High reliability, harsh environment performance
View Product Catalog

View Details

ODU AMC High-Density®

> 5,000 mating cycles
High contact density: 2–27 contacts in 3 shell sizes
High reliability, harsh environment performance
View Product Catalog

View Details

ODU AMC® High-Density Chrome-Plated

> 5,000 mating cycles
High contact density: 2–27 contacts in 3 shell sizes
High reliability, harsh environment performance
View Product Catalog

View Details

¹These ODU specific connectors can transmit common data transmission protocols such as USB® 3.2 Gen 1x1, USB® 2.0 and HDMI®, but they are not USB®, HDMI® - standard connectors.
