            AEC-Q100 MEMS Oscillators
                    SiTime's AEC-Q100 oscillators are engineered for ASIL applications with 30 times better robustness


SiTime’s AEC-Q100 oscillators deliver the highest performance, reliability, and robustness making them ideal for replacing legacy quartz oscillators in automotive safety integrity level (ASIL) automotive systems. These MEMS-based solutions are engineered to guarantee the best frequency stability, Allan deviation, jitter, and phase noise under environmental stressors such as rapid temperature changes, airflow, shock, vibration, and noisy power supplies.

Features
AEC-Q100 compliant, Grade 1 (-40°C to +125°C), Grade 2 (-40°C to +105°C), and extended temperature range (-55°C to +125°C) Unique packaging options: SiT2024: SOT23-5 leaded package for best board-level solder-joint reliability in hot/cold and ease-of-use in manufacturing and test SiT8924/8925: Five package options in industry-standard oscillator footprints as small as 2.0 mm x 1.6 mm Excellent frequency stability at ±20 ppm over -55°C to +125°C for best timing margin	Unique programmable output drive strength for EMI reduction Highest reliability at over 1 billion hours MTBF ( < 1 FIT) Best 50,000 g shock and 70 g vibration resistance Lowest vibration sensitivity (g-sensitivity) at 0.1 ppb/g Widest frequency range of 1 MHz to 137 MHz with 6 decimal places of accuracy Supply voltage options of 1.8 V or 2.5 V to 3.3 V
Applications
Electronic control units (ECUs) ADAS systems Camera modules LIDAR	In-vehicle Ethernet and Datacom Infotainment systems Automotive black boxes Automotive XTAL replacement

Automotive AEC-Q100 Products

	Image	Manufacturer Part Number	Description	Available Quantity	Price	View Details
		SIT9387AE-2B1-33E300.000000G	MEMS OSC XO 300.0000MHZ LVDS SMD	0 - Immediate	$35.38	View Details

Published: 2017-04-27
