The HMC6343 is a 3-Axis tilt compensated compass module in a 9mm x 9mm x 1.9mm LCC surface mount package. This device includes a 3-Axis magnetoresistor and a 3-Axis accelerometer to provide a heading accuracy of about 2.5 degrees over tilt. The tilt range is ±60 degrees with a ±80 degree extended tilt range. The HMC6343 is the smallest, lowest cost, six-axis tilt compensated compass solution available by Honeywell.
